Diagnosis and management of free-floating filling defect in carotid artery—a case report

Jianbin Zhang1, Zhiyong Zhou2, Xueqiang Fan1

1Department of Cardiovascular Surgery, China-Japan Friendship Hospital, Beijing, China; 2Department of Vascular Surgery, People’s Hospital of Xing’an League, Inner Mongolia, China

Correspondence to: Xueqiang Fan. Department of Cardiovascular Surgery, China-Japan Friendship Hospital, No. 2 Yinghua East Road, Beijing 100029, China. Email: fanxueqiang0501@yeah.net.

Abstract: Free-floating filling defect in carotid artery is a relative rare condition. The reported incidence varies from 0.05% to 0.7% based on different studies. The pathological nature of the filling defect may be ulcerated plaque, intimal flap or free-floating thrombus. Ischemic cerebrovascular events may occur in over 90% of patients with free floating thrombus. So free-floating filling defect can cause disastrous consequences, but the optimal treatment strategy remains controversial. From May 2015 to January 2017, we identified 5 patients with free-floating filling defect in carotid artery in cardiovascular surgery department of China-Japan Friendship Hospital and People’s Hospital of Xing’an League. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient. All these patients were identified with carotid ultrasound and treated with carotid endarterectomy or carotid artery stenting. We reported the clinical features, treatment strategies, and prognosis for these patients. In conclusion, free-floating filling defect in carotid artery is a typical phenomenon for unstable carotid plaque. Subsequent thrombus formation and collapse can cause ischemic cerebrovascular events. Both carotid endarterectomy and carotid artery stenting can achieve good curative effect in certain cases, but the optimal treatment strategy need further investigation.

Keywords: Free-floating filling defect (FFFD); carotid endarterectomy (CEA); carotid artery stenting (CAS); case report


Received: 01 August 2020; Accepted: 01 September 2020; Published: 30 March 2021.

doi: 10.21037/jxym-20-91


Introduction

Free-floating filling defect (FFFD) in carotid artery is a relative rare condition. The reported incidence varies from 0.05% to 0.7% based on different studies (1,2). The pathological nature of the filling defect may be ulcerated plaque, intimal flap or free-floating thrombus (3,4). Ischemic cerebrovascular events may occur in over 90% of patients with free-floating thrombus (5). So FFFD can cause disastrous consequences, but the optimal treatment strategy remains controversial. We present the following article/case in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/jxym-20-91).


Case presentation

From May 2015 to January 2017, we identified 5 patients with FFFD in carotid artery in cardiovascular surgery department of China-Japan Friendship Hospital and People’s Hospital of Xing’an League. All these patients were identified with carotid ultrasound and treated with carotid endarterectomy (CEA) or carotid artery stenting (CAS).

Case 1: a 59 years old male patient admitted on November 2016 with dizziness and right tinnitus for 2 years. Ultrasonography showed >90% carotid artery stenosis with FFFD in carotid artery for 1 day. The patient has a history of coronary artery disease for 10 years. He has received coronary artery bypass grafting in 2008 and percutaneous coronary intervention in 2015. He also has hypertension for 13 years and takes metoprolol to control blood pressure. CEA was carried out for the patient, ulceration of the plaque could be seen during the surgery (Figure 1). After surgery the patient recovered uneventfully.

Figure 1 Case 1. Ultrasonography (A), sagittal plane (B) and cross section (C) of CTA showed filling defect in the lumen of carotid artery. 3D-construction (D) showed severe right carotid artery stenosis. During CEA, plaque rupture can be seen (D).

Case 2: a 71 years old male patient with dizziness for 3 years. He has a history of hypertension and diabetes mellitus for more than 10 years. Four years ago, the patient received right CEA and patch angioplasty. Computed tomography (CTA) showed ipsilateral carotid artery FFFD at the proximal part of patch. For this patient we carried out CAS and the result was good (Figure 2).

Figure 2 Case 2. Sagittal plane (A) and cross section (B) of CTA showed filling defect in the lumen of carotid artery. We carried out CAS for the patient (C, D).

Case 3: a 69 years old male patient with dizziness and tinnitus for 2 years. The patient received radical gastrectomy for gastric cancer 4 years ago. He has no history of hypertension, diabetes mellitus or cardiovascular disease. CTA showed FFFD in carotid artery. We performed CAS for this patient. The dizziness and tinnitus relieved after CAS (Figure 3).

Figure 3 Case 3. Cross section (A), sagittal plane (B) of CTA and DSA (C) showed filling defect in the lumen of carotid artery. We carried out CAS for the patient (C, D).

Case 4: a 56 years old male admitted because of transient amaurosis fugax for 1 month. Ultrasonography found >90% carotid artery stenosis with FFFD in carotid artery for 4 days. The patient has a history of hypertension for 20 years and hyperlipidemia for 16 years. Four years ago, the patient has suffered from right stroke and recovered without sequelae. Digital subtraction angiography (DSA) showed FFFD in the distal part of common carotid artery. We carried out CEA for this patient, ruptured plaque and thrombosis can be seen during the surgery (Figure 4). No perioperative complication occurred for this patient.

Figure 4 Case 4. Preoperative DSA showed filling defect in the lumen of carotid artery (A). Ruptured plaque and subsequent thrombus formation can be seen during CEA (B, C).

Case 5: a 60 years old male. The patient was asymptomatic, FFFD in right carotid artery was found in routine physical examination with carotid ultrasonography. the patient has a history of hypertension for 2 years and right stroke for 1 year. He also has a history of intracranial cerebrovascular intervention. CTA showed FFFD in carotid artery and we carried out CAS for this patient (Figure 5). No perioperative complication was observed.

Figure 5 Case 5. This is an asymptomatic patient. The patient has previous right cerebral infarction (A). Cross section (B) of CTA showed filling defect in the lumen of carotid artery. We carried out CAS for the patient (C, D, E).

Discussion

FFFD was relative rare and most associated literatures were case reports, among which the largest series consisted of 29 patients (6). However, with the improvement of understanding and development of ultrasonography, the detection of FFFD gradually increased. Funaki et al. identified 21 mobile plaques among 228 patients with carotid artery stenosis with ultrasonography (7). Among the 5 patients in our institution, all were detected by carotid ultrasonography. 4 cases received DSA and 2 failed to display the FFFD. The typical ultrasonographical performance was described by Kume et al. as Jellyfish sign with filling defect in the carotid artery rising and falling in a manner inconsistent with pulsatile carotid artery wall motion (8,9).

The etiology and natural history of FFFD remains unknown. Most are relevant to intimal flap, plaque rupture and subsequent thrombosis (10-13). In 2 cases treated with CEA, we can find 1 was ruptured plaque and 1 was ruptured plaque with thrombus formation. And some FFFD may have relationship with prior surgery or interventional operation. In our study series, 1 patient have received CEA previously and the filling defect was found in the proximal part of the patch. For these patients, the filling defect may be intimal flap and we chose CAS to immobilize the flap. Another patient has received interventional operation for intracranial cerebrovascular disease. The FFFD in this patient may be associated with iatrogenic injury (14). Complete endarterectomy and fixation of the distal intima during CEA and careful management during interventional operation may be important for the prevention of FFFD formation.

It was reported that ischemic cerebrovascular events occurred in most of the cases with FFFD, the pathological basis may be the fall off and embolization of floating substance (15). In our 5 patients, 4 suffered from symptoms including stroke, TIA and other ischemic symptoms. The optimal treatment strategy for FFFD remains controversial. Some investigators recommended anticoagulation and/or antiplatelet treatment for asymptomatic patients (16,17). Delgado et al. (18) reviewed 20 patients, among which 11 received CEA, 2 received CAS and 7 received medical treatment. Funaki et al. (7) identified 21 patients with carotid mobile plaque, all of them were treated with CEA. We prefer to deal with these patients more aggressively to prevent ischemic cerebrovascular events. The exact method depends on the pathological component. When thrombus was suspected, CEA is more suitable. During the procedure, common carotid artery should be clamped first to prevent thrombus fall off. If preoperative examination excluded thrombus, CAS can be a feasible alternative with its minimally invasive nature (19,20).

In conclusion, free-floating filling defect in carotid artery is a typical phenomenon for unstable carotid plaque. Subsequent thrombus formation and collapse can cause ischemic cerebrovascular events. Both CEA and CAS can achieve good curative effect in certain cases, but the optimal treatment strategy need further investigation.
